AM/FM Mode For Selection

23 frequency band, suitable worldwide

Signal Strength Indication

Full 2 Watts RF power

RF Gain Control

ANL-OFF Selector

LOC-DX Selector

ASQ Function

Emergency Channel 9/19

Squelch Control

Scan Function (automatic search of busy channels)

Memory channel (M1-M4) Selection

PA Function

LED back-light

Channels                   40AM/FM

Frequency range            25.615-28.305 MHZ

Frequency control               P.L.L.

Operating temperature          -10°/+55

Power supply                 13.8Vdc±15%

Size                     160(W)×44(H)×140(D) mm

Weight                       About 1.3kg

Receiver

System                     Double conversion with CPU controlled

IF                        1°10.7MHz / 2°450KHz

Sensitivity                  -118dBm@12dBm SINAD (FM)

                           -107dBm@12dBm SINAD (AM)

Audio output                 2.5W@ 10% THD,16 ohm loading

Audio distortion                    <8% at 1 KHz

Image rejection                         50dB

Current consumption                   180mA(stand-by)

Transmitter

Maximum RF output             4W(@13.8VDC)

Carrie freq. error                  < +/- 800Hz

Modulations               60% to 70%@8mV 1KHz audio tone input(AM)

                         80% to 90%@20mV 1KHz audio tone input(AM)

                         1.5KHz@8mV 1KHz audio tone input(FM)

                          2KHz@50mV 1KHz audio tone input(FM)

Spurious emissions                   60dBc(typical)

Frequency response                from 40 to 2500 Hz

Output impedance                 RF 50 ohm unbalanced

Current consumption                 1.5A(modulation)
